Corrosion Testing Coupon
Jennings Anodes test coupons are a simple yet effective tool for providing a quantitative estimation of corrosion rates occurring in an operating system. They also provide a visual indication of the type of corrosion which may be occurring in the monitored system.
Additional information
| Metal Sheet Material | 20# Carbon Steel |
|---|---|
| Plastic Box Size | 3.9” x 3.9”x 3” (100×100×75mm) |
| Exposed Sheet Size | 3.9” x 3.9” (100 x 100 mm) |
| Cable | 1 x 10 mm² XLPE/PVC Cable, 10 m |
Description
Description
Standard metal test sheet suspended in the test vessel, on-site inspection heat exchanger or test pipeline for corrosion determination. It is used to detect or evaluate the corrosion condition of cooling water system. Generally, the pre processed and weighed metal test pieces are placed in the test system for a period of time, and then taken out to observe the corrosion, clean and weigh. Determine the weight loss degree of metal corrosion, type of corrosion and pitting depth, etc. In addition to the influence of corrosive media, the data of metal hanging pieces are also related to the surface treatment, placement position, exposure time and metallurgical method of samples.
Parameters
Testing
Packaging Information
Remarks: Custom packing is available upon request.
We have strict packing protocols to guarantee safe delivery of our products. Clear shipping marks and documentation make delivery acceptance straightforward and simple.
Shipping Documents:
- Proforma invoice
- Packing list
- Testing reports (Chemical Composition, Electrochemical Properties Test, Certificate of Compliance)
- Certificate of origin (upon request)
